Bihl+Wiedemann BWU1777 AS-i 3.0 PROFIBUS Gateways

To confirm availability, request a quote, or place an order, contact our sales team directly. We are ready to assist with compatibility checks, pricing, and lead times.

Leonia |  Email: sales11@amikon.cn |  WhatsApp: +86 18030175807

The Bihl+Wiedemann BWU1777 is an AS-i 3.0 PROFIBUS DP gateway designed to provide efficient communication between AS-i networks and PROFIBUS systems. Featuring two integrated AS-i 3.0 masters, the module enables simultaneous management of two AS-i circuits using a single gateway and one shared AS-i power supply. The device supports PROFIBUS communication according to IEC 61158, with automatic baud rate detection ranging from 9.6 KBaud up to 12000 KBaud. Through DP functionality, AS-i slave data is mapped directly as I/O data within the PROFIBUS system, allowing full diagnosis and configuration via the DP master.
The Bihl+Wiedemann BWU1777 is built for industrial reliability, offering integrated diagnostics such as AS-i earth fault detection, noise detection, and duplicate address recognition. A clear LCD display provides real-time information including slave addresses and error codes, while multiple LED indicators give immediate status feedback for power, communication, and configuration conditions. Housed in a stainless steel enclosure, the module ensures durability and stable operation within a temperature range of 0°C to +55°C. With compact dimensions and IP20 protection, the Bihl+Wiedemann BWU1777 is well suited for control cabinet installation in demanding automation environments.

Manufacturer: Bihl+Wiedemann
Product Numbers: BWU1777
Product Type: AS-i 3.0 PROFIBUS Gateways
Place of 0rigin: Germany
Operating current: approx.250 mA(PELVvoltage)
PROFIBUS interface: according IEC 61 158
Serial interface: RS232
Baud rates: 9,6 KBaud up to 12000 KBaud, automatic recognition
DP function: imaging of the AS-i slaves as I/O Data of the PROFIBUS complete diagnosis and configuration via the DP Master
AS-i cycle time: 150 us*(number of slaves + 2)
Display

LCD: AS-i slave adresses, error codes

LED green (power): voltage ON

LED green (PROFIBUS): PROFIBUS Master recognized

LED red (config error): configuration error

LED green(UAS-i): AS-i voltage OK

LED green (AS-i active): AS-i normal operation active

LED green (prg enable): automatic address programming enabled

LED yellow (prj mode): master is in configuration mode

Buttons: 4
Voltage of insulation: >500V
EMC directions: EN 61000-6-2,EN 61000-6-4
Ambient operating temperature: 0°C ... +55°C
Storage temperature: -25°C...+85°C
Housing: AS-i master housing in stainless steel
Dimensions (L, W, H in mm): 120/75/83
Protection category DIN 40 050: IP20
Weight: 460 g
