1900/65A Universal Device Monitor

Features

24-bit ADC conversion

Four vibration/position/speed inputs

Four temperature inputs

Configurable scale factors and full scale ranges

Internal OK checking with status

Independent Alert and Danger setpoints

200-entry event list

Six relay output

Relay operation is programmable

Buffered outputs for each transducer channel

Four configurable 4-20 mA recorder outputs

The Bently Nevada 1900/65A Universal Equipment Monitor is designed to continuously monitor and protect devices

used in various applications and industries. The low cost of monitors makes them an ideal solution for general-purpose

machines and processes that can benefit from continuous monitoring and protection.

The 1900/65A provides four sensor inputs and four temperature inputs. The software can configure each sensor input

to support 2-wire and 3-wire accelerometers, velocity sensors, or proximity sensors. Each temperature input supports

E, J, K, and T type thermocouples as well as 2-wire or 3-wire RTDs.

The 1900/65A provides six relay outputs, four 4-20 mA recorder outputs, and a dedicated buffered output. Users can use

the 1900 configuration software to configure relay contacts, turn them on or off based on the OK, Alert, and Danger states

of any channel or channel combination, and provide data for any variable from any channel on any recorder output.

The dedicated buffer output can provide a signal for each transducer input.
