HBM 1-G070A-2 Torque/RPM Adapter

Inquiry us

Basic info

Part number: 1-G070A-2

The 1‑G070A‑2 is a Torque/RPM adapter designed by HBM for the Genesis series of data acquisition (GEN DAQ) mainframes. This product is primarily used to connect torque sensors to GEN DAQ mainframes, enabling high-precision torque and speed measurements in test benches and automated test systems. Compared to conventional connections, the use of differential signals significantly improves interference immunity, making it particularly suitable for use in noisy industrial environments.

Product description: Torque/RPM Adapter

Packaging: Original packaging

Delivery time: 1-3 days

Quality: 100% original and 100% brand

Service One-stop

Shipping Port: Xiamen, China

MOQ: 1 Piece

Specifications

Supported Torque Sensors: Up to 2
Torque Interface: Supports HBM T12/T40B or similar models
Speed Interface: Supports speed (RPM), direction signal, and reference pulse
Signal Type: RS-422 differential signal for enhanced noise immunity
Output: Supports dual-channel RS-422 output for torque and speed input and output
Supported Sensor Types: HBM torque sensor or universal binary, frequency, and A, B, and Z incremental encoders
Interface Connectors: 15-pin Sub-D (sensor input/output), HD-22 Sub-D (event/counter)
Power Supply: Sensor power can be supplied via an adapter (optional)
Environmental Specifications: Operating Temperature: 0°C to +40°C, Storage Temperature: -25°C to +70°C, Humidity: 0–80%; IP20 protection rating; Complies with IEC 60068 series shock and vibration tests; Conforms to various electrical safety and electromagnetic compatibility standards
