Pepperl+Fuchs KFD2-STC5-1 SMART Transmitter Power Supply

Pepperl+Fuchs KFD2-STC5-1 SMART Transmitter Power Supply



Manufacturer: Pepperl+Fuchs
Product Numbers: KFD2-STC5-1
Product Type: SMART Transmitter Power Supply
Country of Origin: Germany
General specifications
Signal type: Analog input
Functional safety related parameters
Safety Integrity Level (SIL): SIL 2
Supply
Connection: Power Rail or terminals 14+, 15-
Rated voltage Ur: 18 ... 30 V DC
Ripple: within the supply tolerance
Power dissipation: ≤ 1 W at maximum load
Power consumption: ≤ 1.6 W at maximum load
Input
Connection side: field side
Connection: terminals 1+, 2-, 3
Input signal: 0/4 ... 20 mA
Input resistance: ≤ 265 Ω terminals 2-, 3 , ≤ 330 Ω terminals 1+, 3
Available voltage: ≥ 16 V at 20 mA terminals 1+, 3
Output
Connection side: control side
Connection: terminals 7+, 8-, 9- (sink)
                      terminals 7-, 8+, 9+ (source)
                      see additional information
Load: 0 ... 800 Ω
Output signal: 0/4 ... 20 mA (overload > 25 mA)
Ripple: ≤ 50 µA eff
External supply (loop): 2 ... 30 V DC

The Pepperl+Fuchs KFD2-STC5-1 SMART is a smart power isolator designed specifically for industrial transmitters. It combines power and signal isolation, serving as a "safe power manager" for field instruments. It delivers stable 24V DC power to the transmitter while electrically isolating and filtering the 4-20mA analog signal it returns, accurately transmitting it to higher-level systems such as PLCs and DCSs.
This device features a compact design and a rugged housing, ensuring stable power supply and pure signal transmission even in industrial environments subject to electromagnetic interference and complex grounding, such as those in the chemical, petroleum, and metallurgical industries. Its two-in-one "power + isolation" feature eliminates the need for separate power supplies and isolators, saving control cabinet space and simplifying system wiring. It is a key component for enhancing safety and reliability in industrial automation signal chains.
