Bently Nevada 148722-01 Proximitor Sensor

Product Model

148722-01

Product Parameters

Proximitor Sensor

Country of origin

USA

Place of shipment

Xiamen, China

Manufacturer

Bently Nevada

Product Type

Test Plug

Test Pin Configuration

3 self-contained pins

Wire Length

1 meter (approx. 3.28 ft) per conductor

Wire Termination

Banana plugs (color-coded)

Wire Color Coding

Typically Yellow, Red, Black (for signal, power, common)

Insulation Material

PFA (Perfluoroalkoxy) rated for high temperature

Operating Temperature Range

-35°C to +100°C (-31°F to +212°F)

Storage Temperature Range

-51°C to +105°C (-60°F to +221°F)

Maximum Voltage

30 Vrms (for banana plug safety)

Material (Housing)

High-impact thermoplastic

Online sensor verification: Enables real-time checking of 3300 XL Proximitor sensor output while machinery is operating.

Non-intrusive diagnostics: Allows signal testing without disconnecting field wiring or interrupting machine operation.

Loop check support: Facilitates end-to-end loop testing of proximity measurement circuits for system validation and troubleshooting.

Signal access for measurement tools: Provides direct access to sensor signals via banana plug outputs for multimeters, oscilloscopes, or monitoring devices.

Standardized connection interface: Uses three self-contained test pins that directly match 3300 XL Proximitor sensor terminal strip spacing for secure and repeatable connection.

Fault detection and troubleshooting: Helps identify wiring issues, sensor drift, or signal abnormalities in vibration and displacement monitoring systems.

Maintenance efficiency improvement: Reduces downtime by allowing diagnostics to be performed while equipment remains in service.

Error reduction in field wiring: Minimizes risk of incorrect reconnection or wiring mistakes during maintenance procedures.

Supports condition monitoring programs: Enhances predictive maintenance workflows for turbines, compressors, pumps, and other rotating machinery.

Improved measurement reliability: Ensures consistent and repeatable signal verification even in harsh industrial environments.
