GE PCIE-5565PIORC-100A00 Reflective Memory PCI Express Node Card

Manufacturer: GE

Product Model: PCIE-5565PIORC-100A00

Product Type: Reflective Memory PCI Express Node Card

Place of 0rigin: USA

RAM

• 128 or 256 MB

Transfer Specifications

• 43 MB/s (single longword accesses) to 170 MB/s (64-byte bursts) non-redundant transfer rate

• 20 MB/s (single longword accesses) to 87 MB/s (64-byte bursts) redundant transfer rate

PCI Transfer Rate

• 132 MB/s (33 MHz/32-bit bus), 264 MB/s (33 MHz/64-bit bus or 66 MHz/32-bit bus), or 528 MB/s (66 MHz/64-bit bus), with automatic throttling to the available link data rate as FIFOs begin to fill

• PCI Express transfer rate: 4 lanes at 2.5 Gbit/s

Environmental Specifications

• Operating temperature: 0°C to +65°C, with forced-air cooling

• Storage temperature: -40°C to +85°C

• Relative humidity: 20% to 80%, non-condensing

Power Requirements

• 0.7 A maximum at +12 VDC (±5%) and 0.6 A maximum at +3.3 VDC

Mechanical Specifications

• Dimensions: 6.6 in (length) × 2.713 in (height)

• Weight: 0.2 lb

Cooling Requirements

• 300 LFM

MTBF (Bellcore)

• 607,680 hours

Cable Support

• Simplex cable: up to 820 ft (250 m)

• Duplex cable: up to 721 ft (219.7608 m)

Supported Operating Systems

• Microsoft® Windows® XP

• Microsoft® Windows® 7

• Linux®

• VxWorks®

GE PCIE-5565PIORC-100A00 is a low-profile PCI Express Reflective Memory node card with a 2 GIGA Baud interface, 128 MB memory, and multimode fiber transmission. Engineered for highly deterministic and tightly timed performance, the card moves large amounts of data quickly and shares data in real time among similar or different network nodes. The short bracket supports low-profile PCIe slots, while an included tall bracket kit allows installation in standard PCIe slots. GE Reflective Memory technology provides implementation simplicity, minimal software overhead, and the deterministic performance required by real-time networking applications.

GE PCIE-5565PIORC-100A00 fits into existing hardware and operating system environments, integrating diverse platforms into a single shared-memory network. The card is well suited for aircraft and power plant simulators, automated test systems, ship and submarine simulators, engine test stands, industrial process control, high-speed data acquisition, aluminum rolling mills, and PLC applications. Support for Microsoft Windows XP, Windows 7, Linux, and VxWorks improves system flexibility, while long-term product availability, ease of integration, robust lifecycle management, and global support help maintain reliable operation throughout the product lifecycle.
