General Electric A06B-6087-H155 Power Supply Module

✣ Product Information ✣

General Electric A06B-6087-H155 is an Alpha-series PSM-55 power supply module that converts three-phase AC input power into a stable high-voltage DC bus for connected servo and spindle amplifier modules. The unit accepts a rated input of 200 to 230 VAC at 50 to 60 Hz and draws 234 A at 200 V. Its three-phase power architecture supports demanding CNC machine tools with multiple heavy-duty feed axes and high-power spindle systems.
With a rated output of 283 to 325 VDC and 65 kW, General Electric A06B-6087-H155 supplies centralized DC power to downstream drive modules through the machine-tool bus system. The module also supports regenerative power handling by returning braking energy from decelerating motors to the incoming power network. In a typical CNC control cabinet, the power supply module is installed ahead of the servo and spindle amplifiers to distribute power across the complete drive arrangement.

✣ Technical Data ✣

Manufacturer: General Electric
Product Model: A06B-6087-H155
Product Type: Power Supply Module
Place of 0rigin: USA
Rated input: 200-230 V
Amp: 234 A at 200 V
Hertz: 50-60 Hz
Phase: 3-Phase
Rated output: 283-325 V, 65 kW

✣ Need Assistance? ✣

For pricing, stock availability, or additional product information, feel free to contact us.

✣ Why Partner With Us? ✣

Industrial Automation Parts Supply

We supply a wide range of industrial automation components, including PLCs, DCS modules, HMI panels, servo drives, power supplies, I/O modules, communication modules, and other control system spare parts.

Worldwide Shipping

Orders can be shipped to customers in many countries through established international carriers, with delivery options selected according to destination and urgency.

Export Documentation

We provide standard export documents and assist with shipping paperwork to help support international orders.

Careful Packaging

Products are packed carefully before shipment to help reduce the risk of damage during transportation.

Product Sourcing

If a required part is difficult to find, we can help check availability through our supplier network and provide sourcing support whenever possible.

Customer Support

Our team responds to product inquiries, quotations, and order updates, helping customers obtain the information needed before and after purchase.

✣FAQ ✣

1. What function does General Electric A06B-6087-H155 perform in a CNC system?
General Electric A06B-6087-H155 converts three-phase AC power into a high-voltage DC supply for servo amplifiers and spindle amplifier modules.

2. Which input power does General Electric A06B-6087-H155 require?
General Electric A06B-6087-H155 operates from a three-phase 200 to 230 VAC supply at 50 to 60 Hz.

3. How much output power can General Electric A06B-6087-H155 provide?
General Electric A06B-6087-H155 delivers a rated output of 65 kW within a DC voltage range of 283 to 325 V.

4. Can General Electric A06B-6087-H155 support regenerative braking energy?
Yes. General Electric A06B-6087-H155 can return energy generated during motor deceleration to the incoming power network.

5. Where is General Electric A06B-6087-H155 installed in a CNC drive cabinet?
General Electric A06B-6087-H155 is normally installed before the connected servo and spindle amplifier modules as the main power-conversion and DC-bus supply unit.
