Vibro-Meter TQ403 111-403-000-012 Non-Nontact Sensor

—— Contact Us ——

—— Product Information ——

The system is based around a TQ403 111-403-000-012 non-contact sensor and an IQS450 signal conditioner. Together, these form a calibrated proximity measurement system in which each component is interchangeable. The system outputs a voltage or a current proportional to the distance between the transducer tip and the target, such as a machine shaft.
The transducer body is available only with metric thread. The TQ403 111-403-000-012 has an integral coaxial cable, terminated with a self-locking miniature coaxial connector. Various cable lengths (integral and extension) can be ordered.
The TQ403 111-403-000-012 transducer can be matched with a single EA403 extension cable to effectively lengthen the front-end. Optional housings, junction boxes and interconnection protectors are available for the mechanical and environmental protection of the connection between the integral and extension cables.

KEY FEATURES AND BENEFITS
• From the vibro-meter® product line
• Non-contact measurement system based on eddy-current principle
• Ex certified versions for use in hazardous areas (potentially explosive atmospheres)
• 5 and 10m systems
• Temperature-compensated design
• Voltage or current output with protection against short circuits
• Frequency response: DC to 20 kHz (−3 dB)
• Measurement range: 12mm
• Temperature range: −40 to +180 °C

—— Technical Specifications ——

Manufacturer: Vibro-Meter
Product Numbers: TQ403 111-403-000-012
Product Type: Non-Nontact Sensor
Place of 0rigin: Switzerland
Temperature ranges
Transducer: −40 to +180°C with drift <5% (operating)., +180 to +220°C with drift >5% (short-term survival).
Transducer and cable: −40 to +195°C if used in an Ex Zone
Cable, connector and optional protection: −40 to +200°C
Protection rating (according to IEC 60529): The head of the proximity transducer (transducer tip and integral cable) is rated IP68
Vibration (according to IEC 60068-2-26): 5 g peak between 10 and 500 Hz
Shock acceleration (according to IEC 60068-2-27): 15 g peak (half sine-wave, 11 ms duration)
