ABB 5SNG0200Q170300 IGBT Module

>> Reach Out Today <<

Manager: Leonia
Email: sales11@amikon.cn
WhatsApp: +86 180 3017 5807

Fast response and professional support for all automation solutions.

>> Product Information <<

Manufacturer: ABB
Product Numbers: 5SNG0200Q170300
Product Type: IGBT Module
Place of 0rigin: Sweden
Voltage: 1700 V
Current: 2 x 200 A
Configuration: Phase leg IGBT
Operating Temperatur: 150 ºC
VCEsat: 2.65 V
Package Type: 62Pak (62mm wide industrial standard)
Chip Technology: SPT++ (Soft Punch-Through)
Isolation Voltage: 4000 V (AC, 1 min)

The ABB 5SNG0200Q170300 is a 62 Pak phase leg IGBT module designed for high-power industrial applications. It features a voltage rating of 1700 V and dual 200 A current capacity, delivering reliable performance in demanding environments. The module utilizes ABB’s advanced SPT++ (Soft Punch-Through) chip technology, providing ultra-low conduction losses, rugged durability, and smooth switching characteristics that help minimize electromagnetic interference (EMC).
Built with a copper base-plate for low thermal resistance, the 5SNG0200Q170300 ensures efficient heat dissipation and stable operation up to 150 °C. Its industry-standard 62 Pak package allows seamless integration into power electronic systems, while the 4000 V isolation rating supports safe high-voltage applications. This combination of high current capacity, low-loss SPT++ technology, and robust packaging makes it ideal for drives, inverters, and other high-performance industrial power modules.
